Description
RED615 ABB line differential protection and measurement and control device
RED615 IEC line differential protection and measurement and control device, as a split phase, double terminal line differential protection and measurement and control device, can perfectly coordinate the overhead lines and cable feeders of public and industrial distribution networks. RED615 can also be used for line differential applications where an in-area transformer is present in the protected feeder section.
The RED615 units between substations communicate via a fiber-optic line or a twin-pair guide line. RED615 features support for the substation IEC61850 communication standard, covering both vertical and horizontal communications, including GOOSE messages with switching and analog signals, and setting based on IEC 61850-8-1.
The RED615 IEC Line differential Protection and Measurement and control device also supports Modbus®, DNP3, and IEC 60870-5-103 protocols.
RED615 provides an optional Ethernet port for loop self-healing communications.
RED615 is a member of the 615 family of ABB Relion® products.
The main advantage
Protection, control, monitoring and management integrated in a single relay protection unit provide a compact and universal solution for public and industrial distribution systems
With selective phase line differential protection, available sensors or traditional CT, PT
With pre-configured standard configuration, including line differential communication, it can be faster and easier to combine, to meet the user’s different application requirements
Pluggable design for quick installation and testing
Large LCD screen with single line chart display, accessible locally or through an HMI that is easy to connect and browse
Thoughtful product life cycle service
The main features
As the main protection of the device, differential protection also has the functions of directional overcurrent, non-directional overcurrent, ground protection, voltage, frequency protection and measurement
RED615 can communicate with each other via optical fiber or guide line
Optional advanced, fast short-circuit and ground fault location
Support for IEC61850 1st and 2nd editions including redundant HSR and PRP, GOOSE and IEC61850-9-2
Support for IEEE 1588 v2 high precision time protocol
Supports Modbus, DNP3, and IEC 60870-5-103 communication protocols
RED615
