The DS200TBCBG1A board is used as the RTD input of the terminal module. The board is located within the <r5> core of the Mark V system.</r5> The kernel’s signal is located on the TBCA terminal board and then written to the TCCA board, also located in the <r5> kernel.</r5> Signals 1-15 are written through the JCC connector. Signals 16-30 are written through the JDD connector. The surface of the board does not have any need to be configured before installation. The DS200TBCBG1A also has a terminal located on the edge of the long board. It has multiple connection points, each of which is numbered to help the user keep track of the wired connections of the board. The board itself is drilled at or near each corner to provide mount/mount options. In addition, the board is labeled with its name and ID number as well as the GE logo to ensure authenticity.
DS200TBCBG1A Terminal emulation card
