The DS200TCDAG1BCB works within the Mark V’s <r1> core.</r1> It is designed to connect to and work with boards such as STCA, UCPB, TCQA, TCQE and TCEA. If you also need any of these components, please search our inventory for these options.
The DS200TCDAG1BCB board has multiple jumpers and can be used for hardware configuration. This includes J1 jumpers for enabling or disabling the RS-232C port, J2 and J3 jumpers for disabling the IONET resistor, and J4 to J8 jumpers for other values.
Additional board components include test points, vertical pin connectors, integrated circuits, pin connectors, resistance network arrays, capacitors, and relays. Connectors are located on the top and bottom edges. The board is marked along the long and short sides for alignment and contains the GE logo to ensure authenticity.
