DS200RTBAG2AFB GE controller



The product description

The DS200RTBAG2AFB is a relay terminal board (RTBA) designed for the General Electric Mark V Board family. The board is available for many GE brand drives and actuators. By mounting the board into the drive cabinet, the user can obtain an additional 10 relays. Both LAN I/O terminals and remote users can drive

Move the relay on the board. Positions K20 to K29 are the circuit board positions for all on-board relays.

DS200RTBAG2AFB includes two types of relays, DPDT and 4PDT. The DPDT model consists of seven relays on the card, including K20 to K26. These types have two type C contacts, each rated 10A. K27 through K29 is the second relay type, 4PDT. 4 PDT relay

Instead of two, there are four C-contacts, each of which is 1A. All ten points are protected by a 130 VAC metal oxide rheostat (MOV).

Each relay contains an internal 110-volt DC coil to ensure their proper operation. If any relay stops working or is damaged, the user can easily remove and replace all ten points. The parameters provided in the DS200RTBAG2AFB Installation and Storage Guide should be followed. This will secure the board and the whole

Integrity of the drive system. Both the device manual and the data manual give detailed installation and wiring instructions for the board. Members of the Mark V board series were initially provided with technical support by manufacturer General Electric.





controller

The controller refers to the main command device that changes the wiring of the main circuit or control circuit and changes the resistance value in the circuit to control the starting, speed regulation, braking and reverse of the motor in a predetermined order. It is composed of program counter, instruction register, instruction decoder, timing generator and operation controller. It is the “decision-making mechanism” that issues commands, that is, it completes the operation of coordinating and directing the whole computer system
