IC698PSA100 GE controller





The IC698PSA100 is a PACSystem RX7i power module manufactured by Emerson Automation and formerly owned by GE Intelligent Platform (GE IP). The PSU is installed in the leftmost slot of any RX7i standard rack, specifically slot 0. It is equipped with spiral input terminals designed for input voltage

The range is 85 to 264 VAC(nominal voltage 120/240 VAC), frequencies 47 to 63 Hz and 100 to 150VDC(nominal voltage 125 VDC). External power connections must be made using AWG #16 (1.3 mm2) solid or stranded copper wire with 75°C(167°F) insulation. For ground connections, use insulation

12 gauge (3.3 mm2) copper wire, grade 75°C(167°F). Proper terminations of GND connections can significantly eliminate or reduce system noise.

The IC698PSA100 provides a maximum power output of 100 watts, which is the total power of all three (3) output terminals, providing nominal values of 4.875 to 5.25 volts, 0-20 AmPs, and 5.1 VDC; 11.64 to 12.6 volts, 0-2 amps, nominal +12 volts DC, and -12.60 to -11.64 volts, 0-1 amps, nominal -12 volts

Direct current (dc). The PSU has a minimum pass time of 15 milliseconds and a minimum hold time of 5 milliseconds. It also has active overvoltage and overcurrent limits, especially 5.7 to 6.7 volts overvoltage protection at + 5V DC; +5 VDC output is 21A+12 VDC output is 2.5 AmPs, and -12 VDC output

The hour is 3.5 amps.

The PSU operates from 0°C to 60°C(32°F to 140°F) and has an isolation rating of 1500 VDC.

IC698PSA100 power module is the Rx7i PACsystem Modern power module produced by GE. It is rated for 120/240 volts AC or 125 volts DC. The input voltage of the power supply ranges from 85 to 264 volts AC or 100 to 150 volts DC. The power module is located on the far left of the Rx7i system baseboard

Is in slot or slot 0. The module is rated at 125 watts. Its output voltages are 5 volts DC, 12 volts DC and -12 volts DC. The IC698PSA100 power module sends logical level signals to the module through the system backplane. The power module has been enhanced in terms of security and protection. It has over current, over

Thermal and overvoltage protection.

The IC698PSA100 power module is equipped with a switch located at the front of the power supply. It helps to enable or disable output channels and does not interfere with AC line inputs. There are LED indicators in the power module, which alert the operator to different conditions. The indicator indicates field normal, output normal and over temperature

The lamp. The minimum power factor of IC698PSA100 power module is 0.99. The isolation voltage in the module is 1500 volt DC. The power supply also provides a 15ms traversal time without affecting DC output, and a 5ms hold time when DC output is lost. The IC698PSA100 power module is required

The operating temperature range is 0 to 60 degrees Celsius. The module is certified to operate in a level 1 zone 2 environment.

-1 amperes at -12 volts DC.
