PM862K02 3BSE081636R1 ABB
Part number: PM862K02 3BSE081636R1
Manufacturer: ABB
Function: Processor unit module
PM862K02 3BSE081636R1 is in stock and will be shipped the same day.
PM862K02 3BSE081636R1 is in the unused and rebuilt state.
To get the best price on PM862K02 3BSE081636R1, please contact us and we will get back to you within 24 hours.
Manufacturer: ABB
Product number :3BSE081636R1
Product model :PM862K02 Redundant processor unit
Clock frequency :67 Mhz
Memory :32 megabytes
Package includes :- 2 PM 862 cpus
– Two TP830 substrates
– Two TB807, ModuleBus terminals
– One TK 850 CEX bus extension cable
– One TK 851 RCU cable
— Two spare batteries (4943013-6)
– No license
Only compatible with 800xA 6.0.2, Compact Control Builder 6.0.0-1 and later
Performance :0.18 ms
Processor type :MPC866
Power supply :24 Volt DC (19.2-30 Volt DC)
Dimensions (H x W x D), approximately: 18.6cm x 11.9cm x 13.5cm
Weight :2.7 kg
Transport weight :4 kg
The CPU board contains the microprocessor and RAM, real-time clock, LED indicator, start button, and compact flash memory interface.
The PM862 controller has two RJ45 Ethernet ports (CN1, CN2) for connecting to the control network and two RJ45 serial ports (COM3, COM4). One of the serial ports (COM3) is an RS-232C port with modem control signals, while the other port (COM4) is isolated and used to connect to the configuration tool. The controller supports CPU redundancy for high availability (CPU, CEX bus, communication interface, and S800 I/O). Simple DIN track connection/discharge procedure using unique slide & lock mechanism. All base plates have unique Ethernet addresses, and each CPU has a hardware identifier. The address can be found on the Ethernet address tag attached to the TP830 Base Plate.
(only support System 800 xa 6.0.2, Compact Control Builder 6.0.0-1 and onwards. See Product Update for more information.)
The software package includes:
2 PM 862 PCS, CPU
2 TP 830 PCS, Baseplate, width = 115mm
Two PCS TB 807 module bus finishers
1 TK850 PC, CEX bus expansion cable
One TK851 PC with RCU cable
2 PC memory backup battery (49443013-6) for each controller 1 PC memory backup battery
Functions and Benefits
ISA Security Authentication – Read more
Reliability and simple fault diagnosis procedures
Modularity, allowing gradual expansion
IP20 protection, no storage module is required
The controller can be configured as 800xA Control Builder
The controller has obtained full EMC certification
Disconnect the CEX bus using a BC810 / BC820 pair
Standards-based hardware for optimal communication connectivity
(Ethernet, PROFIBUS DP, etc.)
Built-in redundant Ethernet communication port
module
A module, also known as a component, is a collection of program statements (a collection of program code and data structures) that can be individually named and independently complete certain functions. It has two basic characteristics: external characteristics and internal characteristics. External features refer to the interface of the module connected with the external environment (that is, the way other modules or programs call the module, including input and output parameters, referenced global variables) and the functions of the module; Internal characteristics refer to the characteristics of the internal environment of a module (that is, the local data and program code of the module).
