PFEA111-20 ABB module

Part number: PFEA111-20



Manufacturer: ABB



Function: Tension controller



Pfea 111-20 in stock, same day delivery.



Pfea111-20 is unused and reconstructed.



To get the best price on PFEA111-20, please contact us and we will get back to you within 24 hours.

ABB Sweden’s PFEA 111 series tension controller is a cost-effective, user-friendly tension controller that provides accurate and reliable control or monitoring of SUM signals for two tensiometers.



SUM signal can be divided into two types of signal A and B, flexible size, can be easily installed and integrated into various types of electric control cabinet.



Pfea111-20 series tension control unit, the basic function is to provide the frequency of 330HZ excitation signal to the tensiometer for signal measurement and processing function, can also provide the output signal to control and indicate



Tension measurement results. The signal processing function of PFEA111-20 is to achieve accurate and reliable signal output by means of amplification, correction and filtering.



Pfea111-20 is the PROFIBUS-DP version of PFEA111-20. In addition to providing the same basic functions as PFEA111, PFEA111-20 also provides fieldbus interaction functions.



Pfea111-20 Technical parameters:

Operating voltage DC24V(18-36V)

Power: 7.5 W

Frequency: 45-65 hz

Number of tension units: 2

Excitation signal current: 0.5 Ams,330Hz

Protection level: IP20 IP65

Operating temperature: +5-+55°C

Green/red LED indicator

Multilingual version



N, KN, KG, LBS, N/M, KN/M, KG/M, PLI showed more units



Pfea111-20 Optional accessories



Insulated amplifier PXUB 201: When the analog output needs insulation requirements, can choose ABB matching PXUB 201 insulated amplifier



PXUB 201 Technical parameters:



Supply Voltage +24 V (20 — 253 V AC/DC)

Current consumption 10 mA + external load

Signal range Input Output

0 — ±10 V 0 — ±10 V

0 — ±10 V 0 — ±20 mA

0 — 10 V 4 — +20 mA

Rated insulation voltage 600 V (basic)



Relay board PXKB 201: DIN-rail mounted and can be used with insulated amplifiers when IP65 protection is selected



PXKB 201 Technical parameters:



Supply voltage +24 V DC

Power consumption 18 mA

Contact data AC 6 A at 250 V

DC 6 A at 250 V



Dc power supply:



PFEA 111 PFEA 112 PFEA 113

SD821 2.5A 6 6 3*

SD822 5 A 12 12 6*

SD823 10 A 24 24 12*



Product ID:3BSE050090R20 ABB Model Name :PFEA111-20 Catalog Description: Tension Electronic equipment PFEA111-20 Type parts and services Measurement and analysis Force Measurement Web Tension measurement PFC300, PFT300 Parts and Services Measurement and analysis Force measurement Paper amplitude tension measurement PFR100 parts and services

Measurement and analysis Force Measurement Paper Width Tension Measurement PFT100 Additional Instructions ABB Model Name :PFEA111-20 Core Credit :0.00 Country of Origin: Swedish Customs Code :85389091 Gross Weight: 0.2kg Invoice Description: Tension Electronic Equipment PFEA111-20 Custom: No Media description: Tension electronic equipment IP20 minimum order

Purchase Quantity :1 piece Order Multiple :1 piece Packing class 1 Gross weight: 0.2kg Packing Class 1 Unit :1 piece Part Type: New Product Name: Unclassified Product Net weight: 0.2kg Product Type: Unclassified only Quote: Unreplaced product ID(old):3BSE028140R20 Unit: Block Stock in (warehouse): Ohio, USA

Technical information :2 weighing sensors input, voltage and adjustable current output A+B filter. Display PFEA111-20 in A-B A, B, and A+B, including CD User Manual UNSPSC:39120000 WEEE Category: The product is not included in WEEE
