Description
3BHE013299R0002 LTC743CE02 intelligent transformer controller
Product Description
I. Product overview
The 3BHE013299R0002 LTC743CE02 is an intelligent transformer controller from ABB. It integrates advanced control technology and protection functions, and can monitor and control various parameters of the transformer to ensure the safe and stable operation of the transformer.
2. Technical specifications
Product Model: 3BHE013299R0002 LTC743CE02
Electrical parameters:
Power Supply type: 24 V
Operating temperature range: -25 C (-13 F) to +70 C (158 F)
Storage temperature range: -25 C (-13 F) to +70 C (158 F)
Device type: Class I
Entrance protection: IP20 (according to IEC 60529)
CE mark: Yes
Mechanical parameters:
Dimensions (W x H x D) : 17.6 mm (0.69 in) x 56.7 mm (2.23 in) x 42.3 mm (1.67 in)
Weight: 90 g (0.20 lb)
Safety certification:
Navy Certificates: ABS, BV, DNV-GL, LR
RoHS compliance: Compliance with Directive 2011/65/EU (en 5081:2012)
WEEE compliance: Compliance with Directive 2012/19/EU
Three, functional characteristics
Intelligent monitoring: It can monitor the various parameters of the transformer in real time, such as voltage, current, temperature, etc., to ensure that the transformer operates in the best condition.
Precise control: Through the precise control algorithm, the precise control of the transformer parameters is achieved, and the operation efficiency of the transformer is improved.
Multiple protection: It has multiple protection functions such as over current, over voltage, under voltage, and over temperature to ensure that the transformer is protected in time under abnormal circumstances.
Communication interface: Support ABB module bus and other communication protocols to facilitate data exchange and remote monitoring with the host computer or other devices.
LTC743CE
Product parameter
Product Model: 3BHE013299R0002 LTC743CE02
Electrical parameters:
Power Supply type: 24 V
Operating temperature range: -25 C (-13 F) to +70 C (158 F)
Storage temperature range: -25 C (-13 F) to +70 C (158 F)
Device type: Class I
Entrance protection: IP20 (according to IEC 60529)
CE mark: Yes
Mechanical parameters:
Dimensions (W x H x D) : 17.6 mm (0.69 in) x 56.7 mm (2.23 in) x 42.3 mm (1.67 in)
Weight: 90 g (0.20 lb)
Safety certification:
Navy Certificates: ABS, BV, DNV-GL, LR
RoHS compliance: Compliance with Directive 2011/65/EU (en 5081:2012)
WEEE compliance: Compliance with Directive 2012/19/EU
Application field
3BHE013299R0002 LTC743CE02 As an intelligent transformer controller, its application field is wide, mainly concentrated in the following aspects:
Power industry:
The transformer is an indispensable part of the power system, and 3BHE013299R0002 LTC743CE02 can monitor and control the various parameters of the transformer in real time, such as voltage, current, temperature, etc., to ensure the safe and stable operation of the transformer.
With its precise control algorithm and multiple protection functions, the controller can effectively improve the operation efficiency of the transformer, reduce the failure rate, and provide a strong guarantee for the stable operation of the power system.
Industrial Automation:
In the field of industrial automation, transformers are important power equipment, and their stable operation is crucial to the normal operation of the entire production line.
3BHE013299R0002 LTC743CE02 Ensures stable operation of transformers in industrial automation systems through accurate monitoring and control, reducing production disruptions and losses due to transformer failures.
Energy Management:
With the continuous development of energy management technology, the monitoring and control requirements of power equipment are getting higher and higher.
3BHE013299R0002 LTC743CE02 Intelligent monitoring and precise control helps the energy management system achieve more efficient and accurate energy scheduling and management, improve energy efficiency, and reduce energy consumption.
Construction field:
In the field of construction, transformers are widely used in various electrical equipment and systems.
The 3BHE013299R0002 LTC743CE02 ensures the stable operation of transformers in the building’s electrical system to provide a safe and reliable power supply to the building.
Other areas:
In addition to the above fields, 3BHE013299R0002 LTC743CE02 can also be used in other fields such as transportation, infrastructure, and provide reliable monitoring and control solutions for various power equipment.
