Description
PFRL101C-1.0KN 3BSE023316R1002 force sensor
Product Description
PFRL101C-1.0kN 3BSE023316R1002 is a force sensor produced by ABB Robotics for the IRB 4600 industrial robot, which is mainly used to measure the force exerted by the robot on the workpiece. Here are some key details about the product:
High precision: PFRL101C-1.0kN has high precision measurement capability to ensure the accuracy of measurement results.
High reliability: The use of high-quality components and strict manufacturing process to ensure long-term stable operation.
Easy installation: Designed for easy installation and maintenance.
Technical specifications:
Rated range: 1.0 kN, that is, the maximum force that the sensor can measure is 1000 Newton.
Resolution: 0.01N, representing the smallest force change that the sensor can distinguish.
Nonlinear error: <0.2%, repeatability: < 0.05N.
Operating temperature range: -20°C to +80°C.
Enclosure protection class: IP67, suitable for use in harsh industrial environments.
Dimensions: Diameter 40 mm x height 50 mm, weight about 0.5 kg.
In addition, the PFRL101C-1.0kN 3BSE023316R1002 force sensor has a wide range of applications, including but not limited to:
Assembly, welding, palletizing, grinding, deburring and other industrial applications.
Test and measurement equipment, medical equipment, automotive industry, aerospace, packaging industry, agricultural machinery, research and education, and weighing equipment.
The sensor is designed to adapt to a variety of industrial environments and provide stable performance.
PFRL101C
Product parameter
Rated range: 1.0 kN, that is, the maximum force that the sensor can measure is 1000 Newton.
Resolution: 0.01N, representing the smallest force change that the sensor can distinguish.
Nonlinear error: <0.2%, repeatability: < 0.05N.
Operating temperature range: -20°C to +80°C.
Enclosure protection class: IP67, suitable for use in harsh industrial environments.
Dimensions: Diameter 40 mm x height 50 mm, weight about 0.5 kg
Application field
Industrial automation: Used in automated production lines to monitor and control the force of robotic arms or automation equipment to ensure accurate operation.
Robotics: In the robot grasp, handling or precision assembly process, to help the robot perceive external forces and achieve finer control.
Test and measurement: In material testing, structural testing, or fatigue testing, the force applied to a sample or structure is measured.
Medical devices: In surgical robots or rehabilitation devices, the forces applied to the patient are monitored and regulated to ensure safety and effectiveness.
Automotive industry: In automotive testing and development, brake force, suspension system pressure, etc.
Aerospace: Monitoring key parameters such as engine thrust and landing gear forces during ground and flight tests of aircraft.
Packaging industry: In packaging machinery, the tension of packaging materials is detected or the force is controlled during the packaging process.
Agricultural machinery: In agricultural equipment, soil compaction is monitored or the force of crops when they are harvested.
Scientific research and education: In scientific research experiments and educational demonstrations, intuitively display the effect of force and measure the size of force.
Weighing equipment: in electronic scales, sky weighing equipment, as a key component of weight measurement.
In addition, the PFRL101C-1.0kN 3BSE023316R1002 force sensor is suitable for the following specific applications:
Pressing and stamping: Measures the forces applied during pressing and stamping operations.
Material testing: Determine the compressive strength of the material.
Weighing system: Integrated into scales and platform scales.
Force monitoring: Monitoring forces in various mechanical systems, such as presses, elevators, and cranes.
Industrial Automation: Measuring the power of automation processes.
