Description
TC810 3BSE076220R1 versatile Ethernet adapter
Product Description
The ABB TC810 3BSE076220R1 is a versatile Ethernet adapter designed for S800 I/O systems for data communication and networking in industrial environments. The following are the detailed features and parameters of the product:
Network connectivity: Provides an Ethernet interface that supports common Ethernet protocols and communication standards, such as TCP/IP, for data communication and exchange with other devices or networks.
Interface type: Features a 2-port (RJ45) switch that allows multiple devices to be connected to a single network, enhancing network flexibility.
Data transmission: Supports high-speed data transmission and real-time communication, and is suitable for application scenarios requiring fast response and large data traffic transmission.
Protocol support: Support for Modbus TCP, PROFIBUS DP, and PROFINET IO protocols ensures compatibility with various industrial automation standards.
Auto-negotiation: Automatically detects and adjusts speed and duplex Settings for optimal performance.
Status indicator: Provides visual indication for troubleshooting and monitoring network status.
Installation method: Supports DIN rail installation for easy installation in industrial environments.
TC810
Product parameter
Technical specifications:
Network media: 100BASE-TX
Connector: RJ45
Data rate: 100 Mbps
Operating temperature: -20 to 60°C (-4 to 140°F)
Protection level: IP20
Dimensions: 114 x 22.5 x 60 mm (4.49 x 0.89 x 2.36 inches).
Applications: Widely used in industrial automation systems, building automation, process control and SCADA systems.
Environment and Certification:
Operating temperature: -40°C to +70°C
Storage temperature: -40°C to +85°C
Pollution Level: Pollution Level 2 (IEC 60664-1)
Relative humidity: 5% to 95%, non-condensing
Altitude: -1000 to 5000 m
Mechanical operating conditions: IEC 61131-2
EMC standards: IEC/EN 61000-6-4, IEC/EN 61000-6-2
Overvoltage Class: Class II (IEC 60664-1)
Protection level: IP20 (IEC 60529)
CE mark: Yes
UKCA: Yes
Electrical safety standards: IEC/EN 61010-1, UL 61010-1, CSA-C22.2 No. 61010-1-12, IEC/EN 61010-2-201, UL 61010-2-201, CSA C22.2 No. 61010-2-201
Ship certification: DNV, ABS
Corrosive atmosphere: G3
RoHS compliance: EU RoHS, UAE RoHS, CN RoHS
WEEE compliance: EU.
Application field
Industrial automation systems: In automated production lines, robot control, automated assembly lines and other occasions, the TC810 3BSE076220R1 can be used to connect and control a variety of sensors, actuators and other automation equipment to achieve real-time data transmission and monitoring.
Power system monitoring: In power monitoring and distribution automation, the module can be used to monitor the operating status of power equipment in real time, remote control and data exchange to ensure the stable operation of the power system.
Traffic signal control: In the field of traffic control such as rail transit and port automation, the TC810 3BSE076220R1 can be used for signal control, vehicle monitoring and security systems to provide reliable network connectivity and data communication.
Building Automation: In an intelligent building management system, the module can be used to integrate lighting, air conditioning, security and elevator systems within the building for centralized monitoring and control.
Process control: In chemical, pharmaceutical, oil and gas, metallurgy and other process control industries, this module is used for process monitoring and control, as well as data display and alarm information display.
SCADA Systems: In a Data Acquisition and Monitoring system (SCADA), the TC810 3BSE076220R1 can be used as a communication component for remote monitoring and control of equipment and processes distributed in different locations.
