Description
VP01 2VAA008172R01 VP01 Valve Positioner module
Product Description
The VP01 Valve Positioner module provides control of the flow of steam, gas, or water through a turbine by precisely regulating the position of the inlet valves. It is intended for modulation of hydraulic actuators via servo valves or I/H converters..
The VP01 performs closed loop control for servo valves utilizing single or redundant position feedback devices, or open loop control for current drive valves. It offers a response time from input to output under 1 millisecond and can generate servo output signals up to 500 milliamps per servo coil output. The feedback devices can be AC or DC LVDT’s and the control output can be Proportional-Integral or Proportional-Only.
The VP01 Valve Positioner controls the flow of steam, gas, or water thru a turbine by precisely regulating the position of inlet valves
16-Bit resolution of analog inputs & outputs
Input signals are updated every millisecond
Coil drive surrents up to 500mA
Support for several types of position feedback devices
Sinusoidal excitation signals from 1.05 to 8.96 Vrms and frequencies from 400 to 15,000 Hz
2x Form A contact, max 400 mA @ +24 VDC Digital Outputs
VP01 2VAA008172R01
Product parameter
| Article number | 2VAA008172R01 (VP01) |
| Type | Valve Positioner |
| Signal specification | Coil Driver: 502 mA maxPosition FB: 4…20 mA position transducer, AC LVDT 1.05…8.96 VRMS, 400…15,000Hz,Unipolar DC position transducer (0…+12 V),Bi-polar DC position transducer (± 6 V or ±12 V) AO: 4…20 mA (System Powered)DI: 24 VDC, 6 mA each (Field Power)DO: Form A max 400 mA @ +24 VDC |
| Life cycle status | ACTIVE |
| Number of channels | 12 |
| Signal type | 2x Coil Driver, 2x Position FB, 2x AO, 3x DI, 2x DO, 1x AI |
| HART | No |
| SOE | Yes |
| Redundancy | Yes |
| Form factor | Standard (190 mm) |
| Mounting | Horizontal Row or Vertical Column |
| MTBF (per MIL-HDBK-217-FN2) | PR E: 169,924 Hours |
| MTTR (Hours) | 1 Hours |
Application field
| Module power requirements | 24 VDC ± 5%, 330 mA typical, 500 mA max (up to 2.0 A inrush) |
| Module power connection | POWER TB on cHBX01L or VBX01T |
| Field IO power | Analog Output: Max 60 mA @ +24 VDC ±5 % Coil Driver: ±15 VDC ±5 %, 50 mA max. + load current -OR- ±24 VDC ±5 %, 50 mA max. + load current. |
| Field IO Power, Digital Outputs | Coil Driver: ±15 VDC ±5 %, 50 mA max. + load current. OR±24 VDC ±5 %, 50 mA max. + load current. |
| Overvoltage category | Category I for power, inputs or outputs. Tested according to EN 61010-1 |
| Max field cable length | 600 meters (1968 feet) |
| Number of Channels | 12 Total (2x Coil Drivers, 2x Position FBs, 2x AO, 3xDI, 2x DO, 1xAI) |
| Signal ranges and types | Coil Driver Output (2): ± 502 mA maxPosition Feedback (2): AC LVDT (1.05…8.96 Vrms, 400…15,000Hz), 4…20 mA position transducer, Unipolar DC position transducer (0…12 V), Bipolar DC position transducer (±6 V or ±12 V)Analog Ouputs (2): 4…20 mA (System Powered)Digital Inputs (3): +24 VDC, 6 mA each (Field Powered)Digital Outputs (2): 1-Form A Contact, +24 VDC max 400 mAExt. Digital Outputs (4): 2-Form C Contact, 3A @ 150 VDC, 5A @ 120 VAC Analog Input (1): 4…20 mA (Field Powered) |
| SOE timestamp accuracy | 1 msec resolution for 24 & 48 VDC |
| Output response time | Max 1 msec |
| A/D Conversion | 2x 24-Bit A/D converters, each with 4 inputs and embedded filtering |
| A/D Resolution | 16-Bit I/O resolution |
| A/D Update rate | 1.5 msec for all channels |
| D/A Resolution | 16-Bits |
| Field signal to Logic isolation | UL1577 1000 VRMS for 1 minute |
| Channel isolation | 500 VRMS at 60 Hz for Digital I/O |
| Open circuit detection time | Max 1 msec |
| Short circuit protection | Coil Driver: 506 mA nominal output current limitLVDT: 150 mA nominal output current limit |
