1771-IBD/B Allen-Bradley discrete input module

1771-IBD/B  Allen-Bradley discrete input module

The Allen-Bradley 1771-IBD is a discrete input module from the 1771 product bulletin.

It has Sixteen (16) 10-30VDC sink input channels with Minimum On-state Voltage 10VDC and Maximum Off-state Voltage of 5VDC.

It is compatible for installation to all 1771 I/O chassis except 1771-A1, -A2 and A4.

Category: Tags:

Description

Technical Specifications for 1771-IBD/B

Manufacturer Rockwell Automation
Module Type Digital DC Input Module
Part Number/Catalog No. 1771-IBD
Brand Allen-Bradley
Series 1771 Product Bulletin
No. of Inputs Sixteen (16) Inputs
Operating Voltage Range 10 to 30VDC
Input Delay Time, OFF to ON 1 ms
Input Delay Time, ON to OFF 1 ms or 6 ms
Power Dissipation 7.3 Watts (max.), 1.0 Watts (min.)
Thermal Dissipation 24.7 BTU/hr (max.), 3.4 BTU/hr (min.)
Backplane Current at 24 Volts 130mA @ 5V dc +5%
Compatible chassis All 1771 I/O chassis except 1771-A1, -A2, and -A4
Keying Between 10 and 12; Between 16 and 18
Field Wiring Arm Cat. No. 1771-WH

The Allen-Bradley 1771-IBD Series B Input module is equipped with a unique assembled plastic cover that is only compatible with the 960364-05 and 961344-01 products. This cover is installed close to the backplane edge connector pins on the components side of the circuit board. Ensure that this cover is never used with any other module. The 1771-IBD Series B module is a 10-20V DC input supply module and it is fully compatible with all other chassis except the 1771 A1, A2, and A4 chassis or any other discrete output module may be used within the same module group. The 1771-IBD Series B Input Module requires 130mA from the output supply which is the 1771 I/O chassis backplane supply. Operators can drive the terminals directly on a 10-30V DC input module from any terminals of the following input channels; the 1771-OBV, 1771-OBD, and 1771-OQ.

The module has a selectable off-delay filter time of 1ms and 6ms and you can use either. When shipped, the module is pre-set to 1ms and for switching to 6ms users will need to power off the I/O chassis and then sliding their fingers on the jumper to roll over to 6ms. The off-delay filter-time configuration plug is on top-left edge of the printed circuit board. Keying of the 1771-IBD Series B Module can be done from any slot between pins 10-12 and 16-18, as long as it is not the left-most slot that is meant for adaptors and processors. There are indicators on the front panel of the module with a green one showing that the module is active and sixteen others for the 16 input channels indicated in red when powered. The minimum off-state current of the 1771-IBD module is 2.0mA at 5V DC and the maximum off-state current of 5V DC. Please note that operators may only use the same DC power source to power both module to ensure that the ground is at the same power rating.
