Description
20G1ANC170JA0NNNNN frequency converter model
Product Description
20G1ANC170JA0NNNNN Product Description
I. Product overview
The 20G1ANC170JA0NNNNN is a frequency converter model from Rockwell Automation under the Allen-Bradley brand. This inverter is widely used in industrial automation to control the speed and torque of the motor for efficient and precise motor control.
Two, the main technical parameters
Adaptive motor power: Depending on the supplier and the specific application, the adaptive motor power may vary. Some data indicate that the adaptive motor power is 2.2kW, but higher power versions may also be available.
Rated voltage: three-phase AC200-240V (there are also data showing 90KW, AC 380-400V, which may be for different applications or series of parameters).
Control mode: voltage vector control.
Supply voltage: medium voltage.
Product series: Some information mentions that the inverter belongs to the M440 series or 753 series.
Third, product characteristics
High Reliability: Rockwell drives are known for their high quality and stability, ensuring stable operation in a variety of operating environments.
High-precision control: Through advanced control algorithms and hardware design, the inverter can achieve high-precision motor control to meet the needs of a variety of complex applications.
Easy installation and maintenance: Compact design and standardized interfaces make installation and maintenance simple and convenient.
4. Application field
20G1ANC170JA0NNNNN inverter is widely used in power, metallurgy, oil and gas, paper printing, textile printing and dyeing, electronic manufacturing, automobile manufacturing and other industries, used to control a variety of motor equipment, improve production efficiency and quality.
20G11NC072JA0NNNNN
Product parameter
Basic parameters:
Brand: Allen Bradley (Rockwell)
Model: 20G1ANC170JA0NNNNN
Series: Some references refer to M440 series or 753 series
Electrical parameters:
Adaptive motor power: According to the data, the adaptive motor power may be 2.2kW, but there may also be a higher power version
Rated voltage: three-phase AC200-240V (other data shows 90KW, AC 380-400V)
Supply voltage: medium voltage
Control mode: voltage vector control
Properties of DC power supply: voltage type
Other parameters:
Origin: USA
Condition: New original
Warranty: One year (some information mentioned)
Filter: No filter
Additional information:
The inverter is suitable for a variety of industrial applications, such as power, metallurgy, oil and gas, paper printing, textile printing and dyeing, electronic manufacturing, automobile manufacturing, etc.
Before installation and use, read the product manual and installation guide carefully to ensure correct installation and use.
Ensure that the power supply and motor match the parameters of the inverter to avoid overload or underload operation.
Application field
20G1ANC170JA0NNNNN inverter application field
20G1ANC170JA0NNNNN drives play an important role in several industries with their outstanding performance and wide application. The following are the main application areas:
Energy saving application:
In the equipment such as fans and pumps, when the average flow required by users is small, the use of frequency converter for speed regulation can significantly reduce energy consumption. According to the data, in the application of fans and pumps, the use of frequency control can save a lot of energy than the traditional adjustment.
Automation System:
With built-in microprocessor and intelligent control function, inverter has been widely used in chemical fiber industry, glass industry, CNC machine tool control, automobile production line, paper making and other fields. These industries realize automatic control of equipment through frequency converters and improve production efficiency.
Process level and product quality improvement:
The inverter is not only used for speed regulation and energy saving, but also can improve the process level and product quality. In the control of various mechanical equipment such as transmission, lifting, extrusion and machine tools, the inverter can reduce the impact and noise of the equipment, effectively extend the service life of the equipment, and even change the original process specifications to improve the function of the entire equipment.
Motor soft start:
The hard start of the motor will have an impact on the power grid and equipment, while the soft start function of the inverter can make the starting current change from zero, and the maximum value does not exceed the rated current, which reduces the impact on the power grid and extends the service life of the equipment and valves.
Specific industry applications:
Air conditioning load: In the central air conditioning system of office buildings, shopping malls, supermarkets and factories, the inverter drives the refrigeration pump, cold water pump and fan, which can save significant energy.
Crusher load: In metallurgical mining, building materials and other industries, crusher, ball mill and other equipment using frequency converter, the effect is remarkable.
Large-scale kiln and calciner: large-scale industrial rotary kiln (converter) in metallurgy, building materials and other industries adopts frequency conversion control, which improves the reliability and stability of equipment.
Compressor load: widely used in compressors in various industrial sectors, especially high-voltage large-capacity compressors, the use of variable frequency speed regulation can bring small starting current, power saving, optimize the service life of equipment and other advantages.
Mill load: In the metallurgical industry, AC-DC-AC frequency converter has become the trend of AC mill, especially in the light load mill, the frequency converter meets the needs of low frequency load starting, synchronous operation between frames, constant tension control and so on.
To sum up, the 20G1ANC170JA0NNNNN inverter has been widely used in many fields and industries, and provides strong support for the production and development of various industries through its excellent performance and diversified functions.
