Description
2198-P031 10A DC Bus Supply unit
Product Description
The 2198-P031 is a 10A DC Bus Supply unit in the Kinetix 5700 Series servo system, which receives 480VAC three-phase power and has a 55mm mounting size. This module is part of the Kinetix 5700 non-regenerative DC bus power supply, which converts three-phase AC line voltage to unfiltered DC bus voltage without providing any provisions for line regeneration or energy recovery from the motor/load system.
In addition, the 2198-P031 is compatible with a variety of drives, including the PowerFlex 520 Series, PowerFlex 750 series, Kinetix 7000, Kinetix 6000 and Kinetix 6200/6500 series. For the PowerFlex 750 series, especially frames 5 and 6, it is recommended if the DC input public bus driver has DC precharge.
In terms of installation and configuration, it is important to follow all applicable specifications, including wire type, conductor size, branch circuit protection and disconnect devices, to ensure the safe installation of electrical equipment. In addition, factors such as AC line impedance, disconnect switch connections, and ground screw/jumper Settings should be considered.
The 2198-P031 also has certain system size limitations, for example, it must comply with IEC 61800-3 (Class C3) when paired with the 2198-DBRxx-F line filter. Combined motor power cables with all axes on the same DC bus must not exceed 400 m (1312 ft) in length and are also suitable for 2198-P031 DC bus power supplies when paired with a 2198-DBxx-F line filter.
In addition, the 2198-P031 has a built-in contactor enable relay that protects the Kinetix 5700 drive system under overload or other failure conditions. During maintenance or operation, you must ensure that the AC power supply is disconnected before any maintenance is performed to avoid the risk of electric shock.
Finally, the 2198-P031, as part of the Kinetix 5700 system, can be used with other types of DC bus power supplies, such as the 2198-RPxxx regenerative DC bus power supply, to build complex drive system configurations.
2198-S086-ERS4
Product parameter
Model: 2198-P031
Description: Kinetix 5700 10A DC Bus Supply unit for providing DC bus power
Input voltage: 324… 528V AC Three-phase (nominal 480V)
Frequency: 47… 63 Hz
Main AC input current: at 324… For 528V (RMS) three-phase, the value is 11.2A
Output: Unfiltered DC bus voltage
Size: 55mm mounting size
Compatibility: Compatible with a variety of drives, including but not limited to PowerFlex 520 Series, PowerFlex 750 Series, Kinetix 7000, Kinetix 6000 and Kinetix 6200/6500 series
System size limitations: When paired with a 2198-DBRxx-F line filter, it must comply with IEC 61800-3 (Class C3)
Motor power cable length: The combined length of all shafts on the same DC bus shall not exceed 400 m (1312 ft)
Ground configuration: Factory installed ground screws for ground-WYE power distribution
Contactor enabler relay: Built-in to protect the drive system under overload or other failure conditions
Application field
Industrial Automation: The Kinetix 5700 DC bus power supply is suitable for a variety of industrial automation applications, including but not limited to manufacturing, packaging, material handling and more, providing stable and continuous power output.
Motor Drive system: The 2198-P031 power module provides the required power to the servo motor, ensuring precise control and high performance.
System integration: Can be integrated with the ControlLogix® EtherNet/IP communication module or the CompactLogix™ 5370 controller for advanced system control and monitoring.
Scalability: By using accessory modules such as the 2198-CAPMOD-2240 capacitor module and the 2198-DCBUSCOND-RP312 DC-BUS regulator module, the DC bus voltage can be extended to additional inverter clusters.
Mounting flexibility: The 2198-P031 is designed with zero stack mounting tags/notches for compact mounting in the control cabinet.
Safety: A built-in contactor enable relay protects the drive system under overload or other failure conditions.
Environmental adaptability: Suitable for a wide range of ambient temperatures, operating temperatures from 0 to 50 °C and storage temperatures from -40 to +70 °C.
Grounding configuration: Depending on the power supply configuration, you may need to remove the grounding screws. This method applies to ungrounded, angular grounded, and impedance grounded power supplies.
EMC performance: If the ground screw is removed, it may affect EMC performance, so it is not recommended to remove the ground screw in facilities with ground-WYE power distribution.
Maintenance and Troubleshooting: The Kinetix 5700 Series provides user manuals and installation guides to help users install, configure, start up and troubleshoot.
