2711P-T6C5A Allen-Bradley Panelview Plus 600 series operator interface terminal

Description

Technical Specifications for 2711P-T6C5A

The Allen-Bradley 2711P-T6C5A terminal is an operator terminal from the PanelView Plus 6 family of industrial terminals. A touch-enabled color display on the 2711P-T6C5A terminal is used for operator input. The touch technology on the terminal is analog-resistive (4-wire). The touchscreen has a rating of 1 million presses. The technology of the 5.5-inch color display is color active-matrix TFT technology and it has 4.5 x 3.4 inches display area, a 320 x 240 resolution, support for 18-bit color graphics, and 440 Nits of brightness. The backlight on the display is a white LED with a rated working life of 25,000 hours and it is non-replaceable. Timestamps for critical data are provided by an onboard real-time clock. The power backup for the real-time system clock comes from an integrated battery which has a working life of 4 years.

The operating system on the 2711P-T6C5A terminal is the Windows CE 6.0 operating system with extended features and file viewers. The terminal also includes 256 MB of RAM. The nonvolatile memory on the system is 512 MB, out of which approximately 73 MB is available for user data. USB flash drives and SD cards are also supported if additional external storage is required. Communication interfaces available on the 2711P-T6C5A terminal include the RS-232 and USB interfaces (1 USB host and 1 device port). The 2711P-T6C5A terminal works on AC power. The supported range of input voltage is from 100 to 240 Volts AC. The terminal consumes 20 VA typically and the maximum power consumption can reach 35 VA. The weight of the 2711P-T6C5A terminal is approximately 0.594 kilograms. The dimensions of the 2711P-T6C5A terminal are 6.5 x 10.4 x 3.8 inches.

2711P-T6C5A

2711P-T6C5A
