43AP-PA42C/XX-XX pneumatic controller
Product Description
The 43AP-PA42C/XX-XX is a pneumatic controller under the FOXBORO brand for industrial automation and process control applications, particularly temperature control. Here are some of the key features and functions of the temperature controller:
Power requirements: Usually 24 VDC power supply is required, but the voltage may be adjusted according to the actual application scenario.
Input signals: Support a variety of analog input signals, such as 4-20 mA, 0-10VDC, and support for thermocouple (TC) and thermal resistance (RTD) signals for temperature measurement.
Output signal: Mainly provides pneumatic output for controlling pneumatic actuators, such as control valves. The range and characteristics of the output signal may vary depending on the specific configuration.
Display: The controller is usually equipped with an LED or LCD display for displaying process values, set points, output status and other information.
Environmental adaptability: Designed for operation in industrial environments, with temperature resistance, humidity resistance, dust resistance and other characteristics, can adapt to harsh industrial environments.
Communication capabilities: Support a variety of communication protocols, such as Hart, Modbus, etc., in order to communicate with other industrial automation equipment and systems. A serial communication interface, such as RS-232 or RS-485, may also be provided for data transfer to an upper computer or other device.
Control function: Support a variety of control algorithms, such as PID (proportional integral-differential) control, on/off control, etc., to meet different control needs.
Configuration and programming: you can configure and program through the buttons and display on the front panel, or you can communicate with the host computer and use professional configuration software for remote configuration and monitoring.
The FOXBORO 43AP-PA42C/XX-XX temperature controller plays an important role in a variety of industrial control applications with its versatility, flexibility and powerful control capabilities.
43AP-PA42CXX-XX
Product parameter
Model: 43AP-PA42C
Power requirements: Usually requires 24 VDC power supply
Input signals: Support a variety of analog input signals, such as 4-20 mA, 0-10VDC, as well as thermocouple (TC) and thermal resistance (RTD) signals
Output signal: Pneumatic output, which may range from 20 to 100 kPa, 3 to 15 psi, or 0.2 to 1.0 bar or kg/cm², depending on configuration
Display: LED or LCD display, display process value, set point, output status, etc
Environmental adaptability: temperature resistance, humidity resistance, dust resistance, adapt to harsh industrial environment
Communication protocol: Support Hart, Modbus, etc
Control algorithm: Support PID (proportional – integral – differential) control, on/off control
Configuration and programming: This can be done remotely via buttons and display on the front panel or via the host computer
Accuracy:
Input to pointer: ±0.5% span for qualified components
Input to output: depends on the measuring element used
Repeatability: 0.2% span
Dead zone: 0.1% span
Ambient temperature effect: Under normal operating conditions, the maximum control point offset at the mid-span for every 55°C (100°F) change is 1% of the input range
Supply pressure effect: Under normal operating conditions, the maximum control point offset at the mid-span for every 7 kPa (1 psi) change is 0.2% of the input range
Air consumption: 0.5 m³/h (0.3 cfm) under standard conditions
Output scale: 0 to 200 kPa, 0 to 30 psi, or 0 to 2 bar or kg/cm², depending on configuration
Installation methods: panel installation, surface installation, pipe installation and hanger installation
Housing: glass fiber reinforced polyester mold with superior corrosion resistance
Finished: The box is grey polyester; Doors are blue textured polyurethane
Data label: Aluminum data label with pressure sensitive adhesive, customer label data of up to 72 characters and Spaces
Approximate weight: 4.8 kg (10.6 lb), excluding components
Application field
Industrial Automation: As part of the field of industrial automation, the 43AP-PA42C/XX-XX is used to control a variety of process variables, including temperature control, for precise process management.
Process control: Specially designed for process control applications such as oil and gas, chemical, pharmaceutical and other industries, offering a variety of control modes including on/off control, proportional control, proportional-integral-differential control, etc.
Temperature measurement: Supports thermocouple (TC) and thermal resistance (RTD) signals for applications requiring temperature measurement and control.
Pneumatic control: Provides pneumatic output for controlling pneumatic actuators such as control valves, suitable for industrial applications requiring pneumatic control systems.
Environmental adaptability: Designed to adapt to harsh industrial environments, it has temperature and humidity resistance and can resist environmental stress to ensure reliability and accuracy in a variety of environmental conditions.
