Name: DS200SDCCG1AFD GE Drive Control Board
Availability: InStock

Description

DS200SDCCG1AFD GE Drive Control Board

Can be transported to all parts of the world. (Exclude areas that cannot be transported under special circumstances! )

If necessary, please contact customer service.

[service contact information]

Tel: 18059884797 (WeChat with the same number)
QQ：3095989363
Email: sales@xiongbagk.cn

Address: Unit 2009, Chuangxiang Center, No.1733, Lvling Road, Siming District, Xiamen

① 24-hour email reply (12 hours);

③ For shipment to countries outside Asia, please contact the seller.

Instruction Manual	GEI-100029
Manufacturer	GE General Electric
Part Number	DS200SDCCG1AFD
Product Type	Drive Control Card
Series	Mark V

DS200SDCCG1AFD

The GE Drive Control Board DS200SDCCG1AFD is the primary controller for the drive. The GE Drive Control Board DS200SDCCG1AFD is populated with 3 microprocessors and RAM that can be accessed by multiple microprocessors at the same time.

You can configure the board using jumpers on the board and software tools. You can load the software configuration tools on a laptop and then download the configuration settings from the board and edit the settings on the laptop. To download the configuration file to the laptop, you can attach the board to a serial cable on the optional LAN communications card and the other end to the serial connector on the laptop. Once you have completed the editing of the configuration file, upload it the board using the serial connection.

If you are having trouble making the serial connection, make sure the serial port on the laptop is configured correctly and also check that the serial cable is attached and fully seated.

Eight jumpers are available on the board for you to configure the behavior of the board. Some of the jumpers are for testing purposes in the factory only and cannot be changed by the user. To change the position of a jumper, hold the jumper with your thumb and forefinger and pull the jumper out of the pins. Move the jumper over the pins for the new position and gently insert the jumper over the pins.

Nine wire jumpers are also available and they can be used to configure the board also.

Frequently Asked Questions about DS200SDCCG1AFD

How many LEDs are on DS200SDCCG1AFD?

DS200SDCCG1AFD has 10 diagnostic LEDs. The LEDs on DS200SDCCG1AFD display fault codes on DS200SDCCG1AFD in either BCD or binary form. The fault number determines which form is used. There are also different blinking modes for fault code LEDs on DS200SDCCG1AFD. Faults 1-399 on DS200SDCCG1AFD have a slow blink rate while faults 400-1023 on DS200SDCCG1AFD have a faster blink rate.

What is DS200SDCCG1AFD used for?

DS200SDCCG1AFD contains the primary control circuitry and software for a drive or exciter. DS200SDCCG1AFD also includes interface circuitry that connects with other boards to form various types of AC and DC motor drives. The DS200SDCCG1AFD interface circuitry controls and processes drive and motor signals as well as customer I/O.

What is the MCP on DS200SDCCG1AFD?

There are three microprocessors on DS200SDCCG1AFD. MCP or Motor Control Processor is one of DS200SDCCG1AFD’s microprocessors. The MCP in DS200SDCCG1AFD is an 80C196 microcontroller with high-speed I/O, conventional digital I/O, analog I/O, timer/counters, and a watchdog timer. The software for MCP on DS200SDCCG1AFD consists of inner loops such as current regulators, and motor/technology specific functions such as DC phase control, AC motion control, and AC general purpose for DS200SDCCG1AFD.

What is the manual for DS200SDCCG1AFD?

The manual for DS200SDCCG1AFD is Manual GEI-100029. This manual is the GE Motors and Industrial Systems Drive Control Card Manual – a manual specific to DS200SDCCG1AFD. This manual provides a functional description of DS200SDCCG1AFD, the manual includes application data for DS200SDCCG1AFD, and the manual gives renewal/warranty replacement information for DS200SDCCG1AFD.
