IC200ALG260 GE VersaMax analog input module

The IC200ALG260 is an analog input module from the Versamax I/O platform. This module is an Eight (8) channel input module that accepts unipolar and bipolar voltage signals specifically, 0 to 10V and +/-10VDC respectively, and current input signals such as 4-20 mA. This module converts the accepted signal to digital data with a resolution of 12 bits. This module operates without an external power supply. It has an optical isolation rating of 250VAC continuous and 1500VAC for a 1-minute duration. Available LED status indicators to the IC200ALG260 to include Internal Power LED (INT PWR LED) and OK LED. It has maximum backplane current consumption of 130 mA at 5 VDC with built-in Loss of internal power diagnostic capability. Configurable parameters to this module include Range select and Mode Select. This module has a maximum input impedance of 126 kOhms in voltage mode and a maximum of 200 Ohms when in current mode. This module has an accuracy of +/-0.3% typical of full scale, +/-0.5% maximum of full scale when operating at 25 Degree Celsius, and +/-1% maximum of full scale at 0-60 Degree Celsius with a resolution of 4?A = 8 counts in the current mode; 2.5 mV = 8 counts in Bipolar, voltage mode and 2.5 mV = 8 counts in unipolar, voltage mode. The module’s channel-to-channel crosstalk rejection is a minimum of 30 dB. This module supports a single-ended wiring configuration wherein analog measurement is taken in reference to the ground wire. It has lesser resistance to Electromagnetic Interference (EMI) therefore, appropriate noise cancellation and signal conditioning are recommended prior to signal termination.
