T8451C ICS TRIPLEX

Description

T8451C ICS TRIPLEX Trusted TMR 24 Vdc Digital Output Module

Can be transported to all parts of the world. (Exclude areas that cannot be transported under special circumstances! )

If necessary, please contact customer service.

[service contact information]

Tel: 18059884797 (WeChat with the same number)

QQ：3095989363

Email: sales@xiongbagk.cn

Address: Unit 2009, Chuangxiang Center, No.1733, Lvling Road, Siming District, Xiamen

① 24-hour email reply (12 hours);

③ For shipment to countries outside Asia, please contact the seller.

Specializing in the world-renowned brand DCS system, robot system, large-scale servo control system and module.

Main brand: Allen Bradley、BentlyNevada、ABB、Emerson Ovation、Honeywell DCS、Rockwell ICS TRICONEX、FOXBORO、Schneider PLC、GE Fanuc、Motorola、HIMA、Prosoft、Woodward、MOOG、

RexrothAnd other imported industrial parts.

• Manufacturer : ICS Triplex
• Product No : T8451
• Product type : TrustedTM Module
• System Supply Voltage Range : 20 to 32Vdc
• Circuit Type : Fault tolerant, fully triplicated with optional line monitoring
• Number of Outputs : 40 Channels
• Independent Power Groups : 5 each of 8 outputs
• Operational Output/Field Voltage Range : 18 to 32V dc
• Output Voltage

  Measurement Range : 0 to 32V dc

  Maximum Withstanding : -1 to 40V dc

  Output Current Rating (Continuous) : 2A per channel limited to 8A per power group

• Maximum capacitance : Pre release 3.5: 30-55uF

  Flashing/pulsing current loads : Release 3.5 is recommended

  Minimum On State Load Current : 50mA

  Output Off State Resistance (effective leakage) : 33O

  Output On State resistance : 0.6O

  Output Short Circuit Protection : Electronic (latching)

  Channel to Channel Crosstalk : >-40dB

• Release 3.5: at least 2800uF at 2A
• Power Consumption

  Field Supply (1A per channel) : 24W

  System Supply (24V) : 24W

• Field Common Isolation

  Sustained Working : ±250V dc

  Maximum Withstanding : ±2.5kV dc

  Output Turn-on/off Delay : 0.5ms

  Sample Update Time : 0.5ms

  Sequence of Events

  Event Resolution : 1ms

  Self-Test Interval : 2 minutes

  Intrinsic Safety : External barrier

  Output Short Circuit Protection : Automatic

  Operating Temperature : -5°C to 60°C (23°F to 140°F)

  Non-operating Temperature : -25°C to 70°C (-13°F to 158°F)

  Temperature change : 0.5ºC/min

  Operating Humidity : 5 – 95% RH non-condensing

• Dimensions (LxWxH) : 30cm x 3cm x 24.1cm
• Weight : 1.13 Kg
• Shipping Weight : 3 Kg

T8451C

T8451C

T8451C

Application industry:

Power plants, steel mills, automobiles, petrochemicals, tobacco, metallurgy

Note: Please follow the instruction manual of this product to install and debug, so as not to damage the product
