Kongsberg MRU-2 Angular rate gyroscope

Description

Technical Description Kongsberg MRU-2：

MRU 2 is commonly used for roll and pitch measurements in offshore riser monitoring systems, dynamic positioning systems, telecommunications antenna compensation systems, and motion damping systems on high-speed ships. The MRU 2 integrates two high-precision accelerometers and two micro-electro-mechanical structure (MEMS) angular rate gyroscopes. The device achieves high reliability through the use of solid-state sensors with no rotating or mechanically worn components

Height [m]
0.14
material
Anodic aluminium oxide
power
Drop voltage (DC)
10
Maximum voltage (DC)
36
Power consumption [W]
4.9
Of the environment
Maximum operating temperature [C]
55
Splash proof casting
Y
Water proof casting
ordinary
Vibration and operating shock tolerances
IEC 60945/EN 60945
Adaptability of electromagnetism
IEC 60945/EN 60945
Direction of installation
In a fixed direction relative to the ship
Droplet operating temperature [C]
– 5
Roll and pitch output
Roll and pitch measurement
Y
Static unit of angular accuracy [RMS]
0.08
Dynamic unit of angular accuracy [RMS]
0.1
Resolution Angle []
0.001
Angular velocity range [/s]
100
Output of acceleration
Measurement of acceleration
Y
Acceleration range m/s2
30
Acceleration noise m/s2 RMS
0.002
Acceleration precision m/s2 RMS
0.01
Interfaces and Data
Ethernet port
Y
RS232 output
Y
RS422 output
Y
Other output ports
Two-way RS-422 from junction box, user configurable RS-232, RS-422
Data output rate
200 Hz, Ethernet UDP/IP 10/100 Mbps
Data output protocol/format
MRU 2 outputs the static and dynamic roll Angle and pitch Angle and the corresponding angular velocity vector. The device outputs surge and swing acceleration. The status of MRU 2 is available online. For this fifth generation MRU data is available through an Ethernet interface and serial line, making MRU data easily distributed to multiple users on board. The output data can be transmitted over two separately configurable serial lines and Ethernet /UDP. Output variables are transmitted as IEEE 32-bit floating point numbers (recommended) or proportional integers. In addition, the ASCII-based NMEA 0183 proprietary statement can be chosen as the data output protocol.
