NXL00045C1N1SSS00 simple and easy-to-use application

Description

NXL00045C1N1SSS00 simple and easy-to-use application

This manual is copyright of Vacon Ltd. All Rights Reserved. The manual is subject to change
without prior notice. The original language of these instructions is English.
In this manual, you can read about the functions of the VACON® AC drive and how to use the drive.
This manual includes a large quantity of parameter tables. These instructions tell you how to read the tables.

• Basic Application = ASFIFF01
• Standard Application = ASFIFF02
• Local/Remote Control Application =ASFIFF03
• Multi-step Speed Control Application =ASFIFF04
• PID Control Application = ASFIFF05
• Multi-purpose Control Application
– NXS = ASFIFF06
– NXP = APFIFF06
• Pump and Fan Control Application =ASFIFF07

NXL00045C1N1SSS00

The Basic Application is a simple and easy-to-use application. It is the default setting on
delivery from the factory. Otherwise select the Basic Application in menu M6 on page S6.2.
See the product’s User Manual.
Digital input DIN3 is programmable.
The parameters of the Basic Application are explained in Chapter 9 Parameter descriptions of
this manual. The explanations are arranged according to the individual ID number of the
parameter.
1.1.1 MOTOR PROTECTION FUNCTIONS IN THE BASIC APPLICATION
The Basic Application provides almost all the same protection functions as the other
applications:
• External fault protection
• Input phase supervision
• Undervoltage protection
• Output phase supervision
• Earth fault protection
• Motor thermal protection
• Thermistor fault protection
• Fieldbus fault protection
• Slot fault protection
Unlike the other applications, the Basic Application does not provide any parameters for
choosing the response function or limit values for the faults. For more information on the
motor thermal protection, see ID704 in Chapter 9 Parameter descriptions.
