57C409 RELIANCE 2 Channel Analog Input Module

57C409 RELIANCE 2 Channel Analog Input Module

The 57C409 was originally created to be an AutoMax Multibus I/O System.
Reliance Electric produced the 57C409 Input Module. There is a very strong possibility that Asea Brown Boveri or Baldor Reliance also sold this module depending on what year it was actually in production. The 57C409 is no longer being supported by any of these original producers.
Add to quote
Category: Tag:

Description

Technical Specifications for 57C409

Instruction Manual J-3637
Manufacturer Reliance Electric
Part Number 57C409
Product Type 2 Channel Analog Input Module
Series AutoMax PLC

Reliance Electric produced the 57C409 Input Module. There is a very strong possibility that Asea Brown Boveri or Baldor Reliance also sold this module depending on what year it was actually in production. The 57C409 is no longer being supported by any of these original producers.

The 57C409 was originally created to be an AutoMax Multibus I/O System. It had an input rating of +/-1, 5, 10, and 20V. This part could allow two input channels to be used in its analog Input Mode.  It had a four to twenty mA current range. The 57C409 had a program interruption and a 12-bit resolution with polarity. This module could use its software to select input filters and sampling rates. This system had the ability to convert analog to digital input values using the sample-and-hold circuits. You can reduce abnormal software signal noise by using a selectable feature on the low pass filters. Doing this will also allow you to have anti-aliasing for higher frequencies.

The 57C409 is comprised of a circuit board with a faceplate that is held in a protecting chassis. This card can be installed into an AutoMax rack to be stored with other modules and cards assigned to the AutoMax system. This card can be slid into a card slot on the backplane of the rack and then properly secured using brackets and screws. There are two brackets on the rack and two on the module. These brackets can also be used to remove the card safely from the rack.

Frequently Asked Questions about 57C409

How many LED indicators are on a Reliance 57C409?
57C409 has four LED indicators on the 57C409 faceplate to show the status of the 57C409 inputs.
What are the channels on 57C409 connected through?
The two channels on 57C409 are connected through a multiplexer to a successive approximation analog to digital converter.
Where do I find information on how to wire 57C409?
For information on how to wire a Reliance AutoMax 57C409, view chapter 3 in the manual for 57C409. The manual is Manual J-3637 and the wiring information for 57C409 is in chapter three of the manual.
