140NOE77101 | Schneider | ETHERNET NETWORK TCP/IP MODULE

140NOE77101 | Schneider | ETHERNET NETWORK TCP/IP MODULE

The 140NOE77101 firmware configuration key features:

  • Integrated 10/100BASE-TX, full duplex capable, shielded twisted pair port
  • Integrated 100BASE-FX multimode, full duplex capable, fiber optic port
  • Embedded HTTP server
  • BOOTP client and server
  • SNMP V2 agent
  • Flash file system
  • Modbus I/O scanner (-00 only)
  • Field upgradeable software over TCP/IP
  • Modbus/TCP client
  • Modbus/TCP server
  • User Programmable Web Pages (-10 only)
  • Factory Cast Application (-10 only)
Category: Tags:

Description

Technical Specifications for 140NOE77101

Part Number 140NOE77101
Manufacturer Schneider Electric
Series Modicon Quantum
Model # 140NOE77101
Alternate Model 140-NOE-771-01
Type IO Modules
Warranty 2 Year
Module format Standard
Product or component type Ethernet network TCP/IP module
Concept Transparent Ready
Web server Class B30
Web services Data Editor (via PC terminal)
Diagnostics via predefined web pages

The Modicon 140NOE77101 manufactured by Schneider Electric is a communication module for use with the Quantum PLC and is used to communicate over an Ethernet network.  It is an Ethernet option adaptor made to fit into a slot on the Modicon Quantum Ethernet module. The 140NOE77101 is installed into a backplane on the standard Modicon Quantum module.

The 140NOE77101 firmware configuration key features:

  • Integrated 10/100BASE-TX, full duplex capable, shielded twisted pair port
  • Integrated 100BASE-FX multimode, full duplex capable, fiber optic port
  • Embedded HTTP server
  • BOOTP client and server
  • SNMP V2 agent
  • Flash file system
  • Modbus I/O scanner (-00 only)
  • Field upgradeable software over TCP/IP
  • Modbus/TCP client
  • Modbus/TCP server
  • User Programmable Web Pages (-10 only)
  • Factory Cast Application (-10 only)

How to configure the 140NOE77101

As shipped from the factory, the 140NOE77101 configuration does not contain an IP address. This is also true if you have not programmed the unit with an Ethernet configuration extension. In this condition, when the 140NOE77101 module starts up, it will attempt to obtain an IP address from the network’s BOOTP server. You can use Concept to assign an IP address, default gateway and sub network mask. See Configuring the Ethernet Address Parameters in Chapter 4. You can also assign IP address parameters using the BOOTP Lite software utility.

What is a BOOTP server?

A BOOTP server is a program which manages the IP addresses assigned to devices on the network. Your system administrator can confirm whether a BOOTP server exists on your network and can help you use the server to maintain the adapter’s IP address.

How to use the 140NOE77101’s BOOTP server

On startup, an unconfigured 140NOE77101 module will attempt to obtain an IP address by issuing BOOTP requests. When a response from a BOOTP server is obtained, that IP address will be used. If there is no BOOTP response received in two minutes, the 140NOE77101 module will use the default IP Address. Consult your system administrator to obtain a valid IP address and appropriate gateway and subnet mask, if required.

140NOE77101

140NOE77101

140NOE77101

140NOE77101

140NOE77101
