Description
PR6423/010-140+CON021 Technical Requirements：
Measuring range
Sensitivity
Target
Measuring error after calibration
Temperature error
Long term drift
Influence of supply voltage
Operating temperature range
Temperature range for storage
Thread of sensorSensor material
Pressure resistance to sensor head
Pressure and differential pressure
resistance at cable outlet
Vibration and shock nominal
values at 25˚ C (77˚ F)
Cable length
Maximum cable temperature
Connection of transducer to
converters
Cable protection
Net weight without armored cable
Net weight with armored cable
Gross weight without armored
cable
Gross weight with armored cable
Static: ±0.5 mm (.019 in)
Dynamic: 0 to 250µm (0 to 10 mil)
Best Suited for 25 to 250µm (1 to 10 mil)
16 V/mm
Electrically conducting steel
Cylindrical shaft
n On measuring collars, if target surface
is less than 20 mm (.79 in)
diameter, then error may be 1% or
greater.
n Error negligible when target surface is
greater than 20 mm (.79 in) in
diameter.
Peripheral speed of shaft: 0 to 2500 m/s
(0 to 8202 ft/s)
Shaft diameter > 25 mm (.98 in)
Nominal gap (center of measuring range):
0.8 mm (.031 in)
< ±1.5% linearity error
Zero point: 200 mV / 100˚ K
Sensitivity: < 2% / 100˚ K
0.3% max.
< 20 mV/V
-35 to +180˚ C (-31 to 356˚ F)
(short term, up to 5 hours, up to +200˚ C
/ 392˚ F)
-40 to +70˚ C (-40 to 158˚ F)
M6 x 0.5 or 1/4” – 28 – UNF – 2A
Stainless steel
10,000 hPa
on request
5 g at 60 Hz
PR 6422/000-000
PR 6422/100-000
PR6423/010-140+CON021
1m (3.28 ft) at transducer
3m (9.84 ft) at extension cable
+200˚ C (392˚ F)
CON 011 and CON 021, Lemo plug
CON 041, blunt cut cable
for screw terminals
Severe and high performance insulation,
PTFE
0.1 kg (.22 lbs)
0.3 kg (.66 lbs)
0.2 kg (.44 lbs)
0.5 kg (1.1 lbs)
